ORDERING INFORMATION Package Shipping NCV4269AD150G SO-8 (Pb-Free) 98 Units/Rail NCV4269AD150R2G SO-8 (Pb-Free) 2500 Tape & Reel NCV4269APD50G SO-8 EP (Pb-Free) 98 Units/Rail NCV4269APD50R2G SO-8 EP (Pb-Free) 2500 Tape & Reel SO-14 (Pb-Free) 55 Units/Rail NCV4269AD250R2G SO-14 (Pb-Free) 2500 Tape & Reel NCV4269ADW50G SO-20L (Pb-Free) 38 Units/Rail NCV4269ADW50R2G SO-20L (Pb-Free) 1000 Tape & Reel SO-8 (Pb-Free) 2500 Tape & Reel Device NCV4269AD250G NCV4269AD133R2G Output Voltage 5.0 V 3.3 V For information on tape and reel specifications,including part orientation and tape sizes, please refer to our Tape and Reel Packaging Specifications Brochure, BRD8011/D. www.onsemi.com 16 NCV4269A PACKAGE DIMENSIONS SOIC-8 NB CASE 751-07 ISSUE AK NOTES: 1. DIMENSIONING AND TOLERANCING PER ANSI Y14.5M, 1982. 2. CONTROLLING DIMENSION: MILLIMETER. 3. DIMENSION A AND B DO NOT INCLUDE MOLD PROTRUSION. 4. MAXIMUM MOLD PROTRUSION 0.15 (0.006) PER SIDE. 5. DIMENSION D DOES NOT INCLUDE DAMBAR PROTRUSION. ALLOWABLE DAM
