1N4004GP, 1N4005GP, 1N4006GP, 1N4007GP www.vishay.com Vishay General Semiconductor Glass Passivated Junction Plastic Rectifier FEATURES * Superectifier application SUPERECTIFIER(R) structure for high reliability * Cavity-free glass-passivated junction * Low forward voltage drop * Low leakage current, typical IR less than 0.1 A * High forward surge capability * Solder dip 275 C max. 10 s, per JESD 22-B106 DO-204AL (DO-41) * Material categorization: for definitions of compliance please see www.vishay.com/doc?99912 TYPICAL APPLICATIONS For use in general purpose rectification of power supplies, inverters, converters and freewheeling diodes for consumer applications. PRIMARY CHARACTERISTICS IF(AV) 1.0 A VRRM 50 V, 100 V, 200 V, 400 V, 600 V, 800 V, 1000 V IFSM (8.3 ms sine-wave) 30 A IFSM (square wave tp = 1 ms) 45 A IR 5.0 A MECHANICAL DATA Case: DO-204AL (DO-41), molded epoxy over glass body Molding compound meets UL 94 V-0 flammability rating Base P/N-E3 - RoHS-compliant, commercial grade VF 1.1 V

1000 1.0A Standard Recovery Rectifiers / DO-41 1N4001 1N4002 1N4003 1N4004 1N4005 1N4006 1N4007 50 100 200 400 600 800 1000 1.0 1.0 1.0 1.0 1.0 1.0 1.0 75 75 75 75 75 75 75 1.0A Standard Recovery Glass Passivated Rectifiers / DO-41 1N4001G 1N4002G 1N4003G 1N4004G 1N4005G 1N4006G 1N4007G 50 100 200 400 600 800 1000 1.0 1.0 1.0 1.0 1.0 1.0 1.0 75 75 75 75 75 75 75 1.0A Standard Recovery Rectifiers / A-405 1N4001L 1N4002L 1N4003L 1N4004L 1N4005L 1N4006L 1N4007L 50 100 200 400 600 800 1000 1.0 1.0 1.0 1.0 1.0 1.0 1.0 75 75 75 75 75 75 75 1.0A Standard Recovery Glass Passivated Rectifiers / A-405 1N4001GL 1N4002GL 1N4003GL 1N4004GL 1N4005GL 1N4006GL 1N4007GL 50 100 200 400 600 800 1000 1.0 1.0 1.0 1.0 1.0 1.0 1.0 75 75 75 75 75 75 75 30 30 30 30 30 30 30 1.5A Standard Recovery Glass Passivated Rectifiers / SMA S2AA S2BA S2DA S2GA S2JA S2KA S2MA 50 100 200 400 600 800 1000 1.5 1.5 1.5 1.5 1.5 1.5 1.5 100* 100* 100* 100* 100* 100* 100* * TT, Terminal Temperature () Reference product datashe

1N4004GP, 1N4005GP, 1N4006GP, 1N4007GP www.vishay.com Vishay General Semiconductor Glass Passivated Junction Plastic Rectifier FEATURES SUPERECTIFIER * Superectifier application (R) structure for high reliability * Cavity-free glass-passivated junction * Low forward voltage drop * Low leakage current, typical IR less than 0.1 A * High forward surge capability DO-204AL (DO-41) * Solder dip 275 C max. 10 s, per JESD 22-B106 * AEC-Q101 qualified * Material categorization: For definitions of compliance please see www.vishay.com/doc?99912 PRIMARY CHARACTERISTICS IF(AV) 1.0 A VRRM 50 V, 100 V, 200 V, 400 V, 600 V, 800 V, 1000 V MECHANICAL DATA IFSM (8.3 ms sine-wave) 30 A Case: DO-204AL (DO-41), molded epoxy over glass body IFSM (square wave tp = 1 ms) 45 A IR 5.0 A VF 1.1 V Molding compound meets UL 94 V-0 flammability rating Base P/N-E3 - RoHS-compliant, commercial grade Base P/NHE3 - RoHS-compliant, AEC-Q101 qualified TJ max. 175 C Package DO-204AL (DO-41) Diode variations Single die Terminals: Matt

N BYD33D RECTRON BYD33D RECTRON BYD33G RECTRON BYD33J RECTRON BYD33M TOSHIBA 1N5818 TOSHIBA 1N5819 TOSHIBA 1N5819 RECTRON BYD73A RECTRON BYD73B RECTRON BYD73D RECTRON BYD73G RECTRON BYD73G RECTRON BYD163 GENERAL SEMICONDUCTOR 1N4003G GENERAL SEMICONDUCTOR 1N4004G INDUSTRY STANDARD - VARIOUS BYX120G INDUSTRY STANDARD - VARIOUS BYX120G INDUSTRY STANDARD - VARIOUS BYX120G MICROSEMI BZD23-C7V5 GENERAL SEMICONDUCTOR 1N4007G INDUSTRY STANDARD - VARIOUS 1N4001ID RECTRON 1N4001G GENERAL SEMICONDUCTOR 1N4001ID FAIRCHILD 1N4002G GENERAL SEMICONDUCTOR 1N4002G ON SEMICONDUCTOR 1N4002G RECTRON 1N4002ID RECTRON 1N4002G FAIRCHILD 1N4002G GENERAL SEMICONDUCTOR 1N4002G FAIRCHILD 1N4003G GENERAL SEMICONDUCTOR 1N4003G ON SEMICONDUCTOR 1N4003G Type 1N4003G 1N4003GP 1N4003GP 1N4004 1N4004 1N4004 1N4004 1N4004G 1N4004GP 1N4004GP 1N4005 1N4005GP 1N4006 1N4006GP 1N4007 1N4007 1N4007 1N4007 1N4007G 1N4007GP 1N4007GP 1N4245 1N4246 1N4247 1N4248 1N4249 1N4249GP 1N4256 1N4257 1N4383 1N

1M120ZS5 1M130ZS10 1M130ZS5 1M150ZS10 1M150ZS5 1M160ZS10 1M160ZS5 1M180ZS10 1M180ZS5 1M200ZS10 1M200ZS5 1N3611GP 1N3612GP 1N3613GP 1N3614GP 1N3957GP 1N4001 1N4001G 1N4001GP 1N4001ID 1N4002 1N4002G 1N4002GP 1N4002ID 1N4003 1N4003G 1N4003GP 1N4003ID 1N4004 1N4004G 1N4004GP 1N4004ID 1N4005 1N4005G 1N4005GP 1N4005ID 1N4006 1N4006G 1N4006GP 1N4006ID 1N4007 1N4007G 1N4007GP 1N4007ID 1N4245 1N4245GP 1N4246 1N4246GP 1N4247 1N4247GP MOTO MOTO MOTO MOTO MOTO MOTO MOTO MOTO MOTO MOTO MOTO MOTO G.S. G.S. G.S. G.S. G.S. G.S./MOTO/I.R. PHIL G.S. PHIL G.S./MOTO/I.R. PHIL G.S. PHIL G.S./MOTO/I.R. PHIL G.S. PHIL G.S./MOTO/I.R. PHIL G.S. PHIL G.S./MOTO/I.R. PHIL G.S. PHIL G.S./MOTO/I.R. PHIL G.S. PHIL G.S./MOTO/I.R. PHIL G.S. PHIL G.S. G.S. G.S. G.S. G.S. G.S. FAGOR Part Number BZX85C120GP BZX85C120GP BZX85C130GP BZX85C130GP BZX85C150GP BZX85C150GP BZX85C160GP BZX85C160GP BZX85C180GP BZX85C180GP BZX85C200GP BZX85C200GP 1N4003GP 1N4004GP 1N4005GP 1N4006GP 1N4007GP 1N4001GP 1N4001GP 1N4001

1N4004GP, 1N4005GP, 1N4006GP, 1N4007GP www.vishay.com Vishay General Semiconductor Glass Passivated Junction Plastic Rectifier FEATURES SUPERECTIFIER * Superectifier application (R) structure for high reliability * Cavity-free glass-passivated junction * Low forward voltage drop * Low leakage current, typical IR less than 0.1 A * High forward surge capability DO-204AL (DO-41) * Solder dip 275 C max. 10 s, per JESD 22-B106 * AEC-Q101 qualified * Material categorization: For definitions of compliance please see www.vishay.com/doc?99912 PRIMARY CHARACTERISTICS IF(AV) 1.0 A VRRM 50 V, 100 V, 200 V, 400 V, 600 V, 800 V, 1000 V MECHANICAL DATA IFSM (8.3 ms sine-wave) 30 A Case: DO-204AL (DO-41), molded epoxy over glass body IFSM (square wave tp = 1 ms) 45 A IR 5.0 A VF 1.1 V Molding compound meets UL 94 V-0 flammability rating Base P/N-E3 - RoHS-compliant, commercial grade Base P/NHE3 - RoHS-compliant, AEC-Q101 qualified TJ max. 175 C Package DO-204AL (DO-41) Diode variations Single die Terminals: Matt

1B06M DF06M 1B06S DF06S 1B08M DF08M 1B08S DF08S 1B10M DF10M 1B10S DF10S 1F1 N/A 1F2 N/A 1F3 N/A 1F4 N/A 1F5 N/A 1H1 UG1001 1H2 UG1002 1H3 UG1003 1H4 UG1004 1H5 UG1004 1H6 UG1005 1N17 N/A 1N18 N/A 1N19 N/A 1N3595US 1N3595US-1 1N3611 1N4003G 1N3611GP 1N3612 1N4004G 1N3612GP 1N3613 1N4005G 1N3613GP 1N3614 1N4006G 1N3614GP 1N3657GP 1N3957 1N4007G 1N4001 1N4001 1N4001A 1N4001 1N4001F 1N4001G 1N5817 N/A N/A N/A N/A N/A N/A SB1100 N/A N/A SBL1645CT N/A SBG1645CT N/A SBR1045D1 SBL1645 N/A SBG1645CT N/A MBR1530CT N/A MBR1540CT N/A MBR1545CT N/A MBRB1545CT DSR15V600 N/A B220A N/A B230A B340A N/A N/A B250A N/A B260A N/A SBG2045CT N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A PR1001L PR1002L PR1003L PR1004L PR1005L N/A N/A N/A N/A N/A N/A 1N5817 1N5818 1N5819 N/A S1D N/A S1D N/A 1N4003G N/A N/A 1N4004G N/A N/A 1N4005G N/A N/A 1N4006G N/A 1N4007G N/A N/A N/A N/A N/A 1N4001G 1N4001G 1N4001GL 1N4001GP 1N4001GPP 1N4001ID 1N4001L N/A 1N4001S 1N4001L 1N4002 1N4002 1N4

1N4004GP, 1N4005GP, 1N4006GP, 1N4007GP www.vishay.com Vishay General Semiconductor Glass Passivated Junction Plastic Rectifier FEATURES * Superectifier application SUPERECTIFIER(R) structure for high reliability * Cavity-free glass-passivated junction * Low forward voltage drop * Low leakage current, typical IR less than 0.1 A * High forward surge capability * Solder dip 275 C max. 10 s, per JESD 22-B106 DO-204AL (DO-41) * Material categorization: for definitions of compliance please see www.vishay.com/doc?99912 TYPICAL APPLICATIONS For use in general purpose rectification of power supplies, inverters, converters and freewheeling diodes for consumer applications. PRIMARY CHARACTERISTICS IF(AV) 1.0 A VRRM 50 V, 100 V, 200 V, 400 V, 600 V, 800 V, 1000 V IFSM (8.3 ms sine-wave) 30 A IFSM (square wave tp = 1 ms) 45 A IR 5.0 A MECHANICAL DATA Case: DO-204AL (DO-41), molded epoxy over glass body Molding compound meets UL 94 V-0 flammability rating Base P/N-E3 - RoHS-compliant, commercial grade VF 1.1 V

2547 1N2548 1N2549 1N2550 1N2551 1N2552 1N2553 1N2554 1N2555 1N2556 1N2557 1N2558 1N2561 1N2562 1N2566 1N2567 1N2568 1N2569 1N2570 1N2571 1N2572 1N2573 1N2849 1N2850 1N2851 1N2852 1N3640 1N3641 1N3642 1N4001 1N4001GP 1N4002 1N4002GP 1N4003 1N4003GP 1N4004 1N4004GP 1N4005 1N4005GP 1N4006 1N4006GP 1N4007 1N4007GP 1N4933 1N4933GP 1N4934 1N4934GP 1N4935 1N4935GP 1N4936 MFT. RECTRON Part No. RECTRON DATA BOOK Page # ITT 6A8 INTL/ITT 1N5400G ITT 1N5401G ITT 1N5402G ITT 1N5404G ITT 1N5404G ITT 1N5406G ITT 1N5406G ITT 1N5407G ITT 1N5407G ITT 1N5408G ITT 1N5408G ITT 6A8 ITT 6A8 ITT 6A8 ITT 6A8 ITT 6A1 ITT 6A2 ITT 6A4 ITT 6A4 ITT 6A6 ITT 6A6 ITT 6A8 ITT 6A8 ITT RL154G ITT RL154G ITT RL155G ITT RL155G INTL/ITT RL154G INTL/ITT RL155G INTL/ITT RL156G GI/MOT/FAGOR 1N4001 GI 1N4001G GI/MOT/FAGOR 1N4002 GI 1N4002G GI/MOT/FAGOR 1N4003 GI 1N4003G GI/MOT/FAGOR 1N4004 GI 1N4004G GI/MOT/FAGOR 1N4005 GI 1N4005G GI/MOT/FAGOR 1N4006 GI 1N4006G GI/MOT/FAGOR 1N4007 GI 1N4007G GI/MOT/FAGOR 1N4933 GI 1N4933G GI

1N4004GP, 1N4005GP, 1N4006GP, 1N4007GP www.vishay.com Vishay General Semiconductor Glass Passivated Junction Plastic Rectifier FEATURES * Superectifier application SUPERECTIFIER(R) structure for high reliability * Cavity-free glass-passivated junction * Low forward voltage drop * Low leakage current, typical IR less than 0.1 A * High forward surge capability * Solder dip 275 C max. 10 s, per JESD 22-B106 DO-41 (DO-204AL) * Material categorization: for definitions of compliance please see www.vishay.com/doc?99912 TYPICAL APPLICATIONS PRIMARY CHARACTERISTICS For use in general purpose rectification of power supplies, inverters, converters and freewheeling diodes for consumer applications. IF(AV) 1.0 A VRRM 50 V, 100 V, 200 V, 400 V, 600 V, 800 V, 1000 V IFSM (8.3 ms sine-wave) 30 A MECHANICAL DATA IFSM (square wave tp = 1 ms) 45 A Case: DO-41 (DO-204AL), molded epoxy over glass body IR 5.0 A Molding compound meets UL 94 V-0 flammability rating Base P/N-E3 - RoHS-compliant, commercial grade VF 1.1 V

STD-002 and JESD 22-B102 E3 suffix meets JESD 201 class 1A whisker test, HE3 suffix meets JESD 201 class 2 whisker test Polarity: Color band denotes cathode end MAXIMUM RATINGS (TA = 25 C unless otherwise noted) PARAMETER SYMBOL 1N4001GP 1N4002GP 1N4003GP 1N4004GP 1N4005GP 1N4006GP 1N4007GP UNIT Maximum repetitive peak reverse voltage VRRM 50 100 200 400 600 800 1000 V Maximum RMS voltage VRMS (1) Maximum DC blocking voltage VDC (1) 35 70 140 280 420 50 100 200 400 600 560 700 V 800 1000 V Maximum average forward rectified current 0.375" (9.5 mm) lead length at TA = 75 C IF(AV) (1) 1.0 A Peak forward surge current 8.3 ms single half sine-wave superimposed on rated load IFSM (1) 30 A Maximum full load reverse current, full cycle average 0.375" (9.5 mm) lead length TA = 75 C IR(AV) (1) 30 A Operating junction and storage temperature range TJ, TSTG (1) - 65 to + 175 C Note (1) JEDEC registered values Document Number: 88504 Revision: 19-Aug-09 For technical questions within your region, please contac

class 1A whisker test, HE3 suffix for high reliability grade (AEC-Q101 qualified), meets JESD 201 class 2 whisker test Polarity: Color band denotes cathode end MAXIMUM RATINGS (TA = 25 C unless otherwise noted) PARAMETER SYMBOL 1N4001GP 1N4002GP 1N4003GP 1N4004GP 1N4005GP 1N4006GP 1N4007GP UNIT Maximum repetitive peak reverse voltage Maximum RMS voltage (1) VRRM 50 100 200 400 600 800 1000 V VRMS 35 70 140 280 420 560 700 V Maximum DC blocking voltage (1) VDC 50 100 200 400 600 800 1000 V Maximum average forward rectified current 0.375" (9.5 mm) lead length at TA = 75 C (1) IF(AV) 1.0 A Peak forward surge current 8.3 ms single half sine-wave superimposed on rated load (1) IFSM 30 A Maximum full load reverse current, full cycle average 0.375" (9.5 mm) lead length TA = 75 C (1) IR(AV) 30 A TJ, TSTG - 65 to + 175 C Operating junction and storage temperature range (1) Note: (1) JEDEC registered values Document Number: 88504 Revision: 02-Apr-08 For technical questions within your region, please conta

of power supplies, inverters, converters and freewheeling diodes for both consumer and automotive applications. MAXIMUM RATINGS (TA = 25 C unless otherwise noted) PARAMETER SYMBOL Maximum repetitive peak reverse voltage VRRM (1) 1N4001GP 1N4002GP 1N4003GP 1N4004GP 1N4005GP 1N4006GP 1N4007GP UNIT 50 100 200 400 600 800 35 70 140 280 420 50 100 200 400 600 Maximum RMS voltage VRMS Maximum DC blocking voltage VDC (1) Maximum average forward rectified current 0.375" (9.5 mm) lead length at TA = 75 C IF(AV) (1) 1.0 IFSM (1) 35 Non-repetitive peak forward surge current square waveform TA = 25 C (fig. 3) tp = 1 ms tp = 2 ms Rating for fusing (t < 8.3 ms) Operating junction and storage temperature range V 560 700 V 800 1000 V A 45 tp = 5 ms Maximum full load reverse current, full cycle average 0.375" (9.5 mm) lead length TA = 75 C 1000 A 30 IR(AV) (1) 30 A I2t (2) 3.7 A2s TJ, TSTG (1) - 65 to + 175 C Notes JEDEC registered values (2) For device using on bridge rectifier application (1) Revision: 28-May-1
